Specifications:

Frequency range
Receive
Transmit
0.030 - 199.999 MHz* 400 - 470 MHz*
1.8 - 1.999 MHz* 3.5 - 3.999 MHz*
7.0 - 7.300 MH* 10.1 - 10.150 MHz
14.0 - 14.350 MHz 18.068 - 18.168 MHz
21.0 - 21.450 MHz 24.89 - 24.990 MHz
28.0 - 29.700 MHz 50.0 - 54.000 MHz*
144.0 - 148.000 MHz* 430.0 - 450.000 MHz*
* Varies according to version
Mode USB, LSB, CW, RTTY ( FSK) , AM, FM, WFM ( Rx only)
No. of Memory Channels 107 ( 99 regular, 6 scan edges, 2 call channels)
Antenna Connector SO-239x2 ( for HF/ 50 MHz and 144/ 430 MHz) / 50©
Frequency stability Less than ± 7ppm from 1 min. to 60 min. after power ON. After that rate of stability less than ± 1 ppm/ hr. at + 25 ° C ( + 77° F) . Temperature fluctuations 0° C to + 50° C ( + 32° F to + 122° F) less than ± 5 ppm.
Current Drain Tx Max 20 A
Rx Standby 1.8A
Max Audio 2.0 A

Temperature Range -10° C to 60° C;
14° F to 140° F
Dimensions
( projections not included) 167( W) X 58( H) X 200( D) mm;
69/ 16( W) X 29/ 32( H) X 77/ 8( D) in
Weight ( approx.) 2.45 kg ( 5 lb 6 oz)
CI-V connector 2 conductor, 3.5 ( d) mm ( 1/ 8 " )
ACC Connector 13 pin
Transmitter
Output Power SSB/ CW/ RTTY/ FM AM
HF/ 50 MHz 5 - 100 W 2 - 40 W
144 MHz 2.5 - 50 W 2 - 20 W
440 MHz 2 - 20 W 2 - 8 W
